Ring Forming/Making Machine
Alias: CNC looping machine, coiling machine, round winding machine, unwinding machine,arc bending machine, rounding machine, rolling machine
1.Application:
This machine is widely used to make all kinds of wires into circle, semicircle or any Angle (concentric Angle) arc. It can also make square, oval workpiece with special molds and adjustable pressure wheel; Non-circular section wire or plate cutter can be processed only by changing the wire wheel, wire feeding wheel and cutter. It is the first choice equipment for electric poles, mining air ducts, environmental protection dust removal frame, fan net cover, lamp shade, handicrafts, flower pots, luggage and box fasteners, daily hardware kitchenware (such as stove frame, wine/cup holder) and other industries to improve product quality, reduce production costs, improve production capacity.
2. Characteristic:
The key parts of the machine adopt imported devices to ensure the service life of the machine.
Our machine has the characteristics of stability, speed and accuracy, and has the advantages of adjusting speed of fast, slow, smooth and trial beating.
Materials for ring forming machine: the wire feeding wheel / cutter is made of excellent alloy steel and vacuum treated, with wear resistance and long service life. The straightening and pressing block is made of cast iron / alloy, etc; The shaft is made of 40Cr or 45# steel, the gear is forged, modulated and high-frequency quenched, and the hardness is as high as hrc55-58 degrees. 3.Main technical parameters:
